DF20A

20 Hp four stroke
DF20A
Features
Multi-point   sequential electronic fuel injection Standard
Over-rev.   limiter Standard
Low oil   pressure caution Standard
Suzuki   anti-corrosion system Standard
Start   system Electric or manual
Suzuki   lean burn control system Standard
Available   with power tilt opt Optional

Specifications
Shaft   length S: 381mm (15")| L: 508 mm   (20")
Starting   system Electric or manual
Weight MS: 44kg | ML: 45kg | ES: 48kg |   EL: 49kg | PTL: 54.5kg
Engine   type SOHV
Fuel   delivery system Electronic fuel injection
No. of   cylinders In-line 2
Piston   displacement 327cm3
Bore x   Stroke 60.4mm x 57mm
Maximum   output 14.7 kW
Full   throttle operating range 5,300–6,300rpm
Steering Remote | Tiller
Oil pan   capacity 1.5 litres
Ignition   system Digital CDI
Alternator E: 12V 12A | M: 12V 6A
Engine   mounting Shear mount
Trim   method Manual | Power tilt
Gear   ratio 2.08:1
Gear   shift F-N-R
Exhaust Through prop hub exhaust
Propeller   selection (pitch) 7"–11" (Alloy)
Fuel   tank capacity Separate 12L
Warranty 5 years for recreational use
